1. The tin balls are melted by laser, and the melted tin balls are sprayed onto the welding parts
to achieve precise welding, thereby ensuring the reliable electrical continuity and welding
strength of the components;
2. Non-contact welding, no flux welding, no cleaning;
2. Non-contact welding, no flux welding, no cleaning;
1. Flux-free soldering, no cleaning, cost saving;
2. Solder ball soldering, stable tin
amount of solder joints, good appearance consistency, improve soldering quality;
3. Realize
precise soldering of tiny soldering positions, solving the problem of manual inability to solder
;
4. High welding speed, increase productivity and save labor costs;
The product is suitable for BGA, VCM, CCM, HDD
 |
 |
 |
 |
 |
 |
| Basic Parameters | Dimensions (mm) | 1310(L)*1150(W)*1800(H) mm |
| Equipment weight | 1600kg | |
| Operating voltage | 220VAC, 50/60Hz | |
| Normal power | 16KW | |
| Working air pressure | 0.4~0.6 Mpa | |
| Working nitrogen pressure | 0.2~0.4 Mpa | |
| Function Parameter | Applicable solder ball diameter specification (um) | 70-1000 |
| Welding speed (ball/sec) | 4~8 | |
| Applicable welding spacing | 0.1mm minimum | |
| Mean time between failures (MTBF) | 4H | |
| Equipment one-time optimization rate | ≥99.5% | |
| Repeatability | ≤0.003mm | |
| Welding accuracy | ±0.01mm | |
| Environmental Parameters | Noise | <70dB |
| Temperature | 10~40℃ | |
| Humidity | 40~70% |
