1. The tin balls are melted by laser, and the melted tin balls are sprayed onto the welding parts to achieve precise welding, thereby ensuring the reliable electrical continuity and welding strength of the components;
2. Non-contact welding, no flux welding, no cleaning;

1. Flux-free soldering, no cleaning, cost saving;
2. Solder ball soldering, stable tin amount of solder joints, good appearance consistency, improve soldering quality;
3. Realize precise soldering of tiny soldering positions, solving the problem of manual inability to solder ;
4. High welding speed, increase productivity and save labor costs;

The product is suitable for BGA, VCM, CCM, HDD

Basic Parameters	Dimensions (mm)	1310(L)*1150(W)*1800(H) mm
	Equipment weight	1600kg
	Operating voltage	220VAC, 50/60Hz
	Normal power	16KW
	Working air pressure	0.4~0.6 Mpa
	Working nitrogen pressure	0.2~0.4 Mpa
Function Parameter	Applicable solder ball diameter specification (um)	70-1000
	Welding speed (ball/sec)	4~8
	Applicable welding spacing	0.1mm minimum
	Mean time between failures (MTBF)	4H
	Equipment one-time optimization rate	≥99.5%
	Repeatability	≤0.003mm
	Welding accuracy	±0.01mm
Environmental Parameters	Noise	<70dB
	Temperature	10~40℃
	Humidity	40~70%
